Temperature & Pressure Valves
Series 100XL temperature and pressure relief valves are used in water heater and hot water storage tank applications to provide automatic temperature and pressure protection to hot water supply tanks and hot water heaters up to 105,000 BTU (British Thermal Unit)/hr (hour). They feature a bronze body with NPT (nominal pipe thread) male inlet and NPT female outlet connections, unique thermostat with special thermo-bonded coating and a test lever. Series 100XL is ASME (American Society of Mechanical Engineers) rated and CSA (Canadian Standards Association) listed. Manufactured to include no more than 0.25\% weighted average lead content on wetted surfaces.
Temperature and pressure relief valve. ASME certified. Rated for 150 P.S.I. pressure and 210 deg. F. 3/4" MIPS inlet and 3/4" FIPS outlet. Extra long 2-1/2" shank. Fits most NAECA III Water Heaters.
Temperature and pressure relief valve for direct installation into hot water tank. Rated for 150 P.S.I. pressure and 210 deg. temperature. 3-3/4" thermostat probe projection. Protects water heaters to 100,000 BTU per hour. 3/4" MIPS inlet and 3/4" F.I.P.S. outlet.
